    MCCB Molded Case Circuit Breakers

    VKM1 series

    Molded Case Circuit Breakers

    1. Application

    VKM1 series of molded case circuit breakers are applied to frequently changeover the circuit of rated insulation voltage of 800V (VKM1-63 is 500V), AC 50/60Hz, rated voltage 690V or below (VKM1-63 is 415V), rated operating current 1250A, or start the motor not frequently (VKM1-800 without motor protection). The breakers provided with overload short-circuit and under-voltage protection function to protect the lines and power equipment from damage.

    The product can be mounted vertically or horizontally.


    2. Technical parameters

    ModelVKM1-63VKM1-125VKM1-250VKM1-400VKM1-630VKM1-800
    Frame current Inm (A)63125250400630800
    Rated current In (A)

    (6),10

    16,20

    25,32

    40,50

    63

    (10),16,20

    25,32,40

    50,63,80

    125

    125,140

    160,180

    200,225

    250

    250,315

    350,400

    400,500,630

    630,700

    800

    Number of poles3423423423423434
    Rated insulation voltage Ui (V)AC500AC800
    Rated working voltage Ue (V)AC415AC415,AC690
    Rated impulse withstand voltage Uimp (V)60008000
    Arcing distance (mm)50100
    Breaking capacity gradeLMLMHLMHLMHLMHMH
    Limit short-circuit breaking capacity Icu (kA)AC415V25503550853550855065100506510075100
    Running short-circuit breaking capacity Ics (kA)AC415V18352235502235503542653542655065
    Operation characteristics (times)ON60003000200015001000
    OFF85007000400040002500
    total1450010000600055003500

    3. Outline and installation dimensions (mm)


    Model

    Pole

    No.

    Outline Dimension (mm)Installation Dimension (mm)
    L1L2L3L4abdHH1
    VKM1-63L376135897525117Φ3.52371
    VKM1-63M376135978225117Φ3.52371
    4100135978250117Φ3.52371
    VKM1-125L2651508967/129Φ4.52668
    392150896730129Φ4.52668
    4120150896760129Φ4.52668
    VKM1-125M26515010585/129Φ4.52668
    3921501058530129Φ4.52668
    41201501058560129Φ4.52668
    VKM1-125H27515010585/129Φ4.52668
    31061501058530129Φ4.52668
    41401501058560129Φ4.52668
    VKM1-250L27516511085.5/126Φ4.53074
    310616511085.535126Φ4.53074
    414016511085.570126Φ4.53074
    VKM1-250M275165125104/126Φ4.53074
    310616512510435126Φ4.53074
    414016512510470126Φ4.53074
    VKM1-250H275165125104/126Φ4.53074
    310616512510435126Φ4.53074
    414016512510470126Φ4.53074
    VKM1-400L315025715110344194Φ763128
    419825715110395194Φ76589
    VKM1-400M315025715110344194Φ763128
    419825715110395194Φ76589
    VKM1-400H315025715110344194Φ763128
    419825715110395194Φ76589
    VKM1-630L318227015511058200Φ762.5134
    4240270155110116200Φ76589
    VKM1-630M318227015511058200Φ762.5134
    4240270155110116200Φ76589
    VKM1-630H318227015511058200Φ762.5134
    4240270155110116200Φ76589
    VKM1-800L321028015010870243Φ765.5105
    428028015010870243Φ765.5105
    VKM1-800M321028015010870243Φ765.5105
    428028015010870243Φ765.5105
    VKM1-800H321028015010870243Φ765.5105
    428028015010870243Φ765.5105
